Essiccatore ad aria compressa refrigerato
Essiccatore ad aria compressa refrigerato
Inlet Pressure: 0.4 – 1.6 Mpa
Rated Air Capacity: 1.5 – 550 m³/min
Compressor Power: 0.35 – 90 kW
Features of the Refrigerated Compressed Air Dryer
Nanxiang refrigerated compressed air dryer is a reliable, efficient and stable device designed to reduce humidity when drying compressed air.
● Equipped with a powerful and efficient cooling control system (thermostatic bypass) to ensure stable exhaust pressure dew point and prevent ice blockages from occurring.
● Reduces the number of alignments or line leaks, in turn reducing energy consumption, as well as the need for repairs on pneumatic tools and pipes.
High temperature air-cooled dryer:
| Project/Model | NX-15HF | NX-2.6HF | NX-3.8HF | NX-5.5HF | NX-6.9HF | NX-8.5HF | NX-11HF | NX-14.9HF | NX-17HF | NX-22HF | NX-24.5HF | HX-28HF | NX-34HF | NX-45HF | NX-55HF | NX-65HF | NX-75HF | NX-85HF | NX-110HF |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Rated Air Capacity (m³/min) | 15 | 2.69 | 4 | 6 | 6.9 | 8.5 | 11 | 14.9 | 17 | 22 | 25 | 28 | 34 | 45 | 55 | 65 | 75 | 85 | 110 |
| Power supply (V/Hz) | lph220v50hz | lph220v50hz | lph220v50hz | lph220v50hz | lph220v50hz | lph220v50hz | lph220v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz |
| Power(kW) | 0.35 | 0.45 | 0.65 | 1 | 2 | 1.65 | 1.94 | 3 | 2.94 | 3.75 | 4.2 | 4.4 | 5 | 7.35 | 8.82 | 9.92 | 11.03 | 11.03 | 14.7 |
| Refrigerant | R134a | R134a | R134a | R134a | R134a | R134a | R134a | R134a | R134a | R134a | R134a | R134a | R134a | R134a | R134a | R134a | R134a | R134a | R134a |
| Calibro da presa d'aria | R1 | R1 | R1 | R1-1/2 | R1-1/2 | R1-1/2 | R2 | R2 | DN65 | DN65 | DN80 | DN80 | DN80 | DN100 | DN100 | DN125 | DN125 | DN150 | DN150 |
| Dimension (H) (mm) | 500 | 500 | 760 | 765 | 895 | 895 | 1005 | 1005 | 1005 | 1250 | 1250 | 1600 | 1600 | 1600 | l800 | 2100 | 2100 | 2100 | 2650 |
| Dimension (W) (mm) | 280 | 280 | 430 | 435 | 485 | 485 | 585 | 585 | 585 | 630 | 630 | 750 | 750 | 750 | 900 | 1010 | 1010 | 1010 | 1050 |
| Dimension (H) (mm) | 530 | 530 | 660 | 765 | 875 | 875 | 1130 | 1130 | 1130 | 1300 | 1300 | 1400 | 1400 | 1400 | 1620 | 1710 | 1710 | 1710 | 2100 |
| Peso (kg) | 32 | 39 | 67 | 80 | 93 | 100 | 180 | 200 | 250 | 280 | 380 | 430 | 480 | 520 | 670 | 860 | 1100 | 1300 | 1500 |
High temperature water-cooled cold dryer:
| Project \Model | NX-11HW | NX-14.9HW | NX-17HW | NX-22HW | NX-24.5HW | NX-28HW | NX-34HW | NX-45HW | NX-55HW | NX-65HW | NX-75HW | NX-85HW | NX-110HW | NX-140HW | NX-168HW | NX-220HW | NX-280HW | NX-320HW | NX-460HW | NX-550HW |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Dimensions (W) (mm) | 585 | 585 | 585 | 630 | 630 | 750 | 750 | 750 | 1000 | 1000 | 1000 | 1000 | 1200 | 1200 | 1500 | 1500 | 1500 | 1500 | 2000 | 2000 |
| Dimensions (H) (mm) | 1130 | 1130 | 1130 | 1300 | 1300 | 1400 | 1400 | 1400 | 1600 | 1600 | 1600 | 1600 | 1800 | 1800 | 2200 | 2350 | 2400 | 2500 | 3000 | 3000 |
| Power supply(V/Hz) | lph220v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz | 3ph380v50hz |
| Dimensions (L) (mm) | 1005 | 1005 | 1005 | 1250 | 1250 | 1600 | 1600 | 1600 | 1900 | 1900 | 1900 | 1900 | 2100 | 2100 | 2700 | 3300 | 3300 | 3300 | 4500 | 4500 |
| Rated Air Capacity(m³/min) | 11 | 14.9 | 17 | 22 | 24.5 | 28 | 34 | 45 | 55 | 65 | 75 | 85 | 110 | 140 | 168 | 220 | 280 | 320 | 460 | 550 |
| Peso (kg) | 160 | 170 | 200 | 280 | 460 | 500 | 650 | 700 | 800 | 950 | 1000 | 1250 | 1900 | 2450 | 3000 | 3300 | 3700 | 4000 | 4900 | 5100 |
| Power(kw) | 1.94 | 2.75 | 2.94 | 3.75 | 4.2 | 4.4 | 5.2 | 7.35 | 8.82 | 9.92 | 11.03 | 11.03 | 14.7 | 18.4 | 30 | 36 | 50 | 55 | 80 | 90 |
| Condenser Water Pipe Diameter | Rc1/2 | Rc1/2 | Rc1 | Rc1 | Rc1-1/2 | Rc1-1/2 | Rc1-1/2 | Rc1-1/2 | Rc1-1/2 | Rc1-1/2 | Rc1-1/2 | Rc1-1/2 | Rc2 | Rc2 | DN65 | DN65 | DN65 | DN80 | DN100 | DN125 |
| Calibro da presa d'aria | R2 | R2 | DN65 | DN65 | DN80 | DN80 | DN80 | DN100 | DN100 | DN125 | DN125 | DN150 | DN150 | DN150 | DN200 | DN200 | DN250 | DN250 | DN300 | DN300 |
| Refrigerant Type | R22 or R407C | R22 or R407C | R22 or R407C | R22 or R407C | R22 or R407C | R22 or R407C | R22 or R407C | R22 or R407C | R22 or R407C | R22 or R407C | R22 or R407C | R22 or R407C | R22 or R407C | R22 or R407C | R22 or R407C | R22 or R407C | R22 or R407C | R22 or R407C | R22 or R407C | R22 or R407C |
Nota:
Note sul numero di modello: “F” indica velocità fissa, “V” indica VSD. A causa delle velocità di rotazione potenzialmente diverse dei motori, le portate d'aria della velocità fissa rappresentano il minimo nell'intervallo (ovvero 30 kW 8 bar 5,67 m³/min), mentre il VSD può raggiungere il massimo a pieno carico.
Tensione standard in 380 V (+/-10%), 50 Hz +/-2% e disponibile per tensioni personalizzate 220/380/440/460 V/60 Hz.
In caso di altitudini elevate, temperature estreme, umidità eccessiva, forte esposizione alla polvere o qualsiasi altro ambiente operativo difficile, siamo in grado di offrire prodotti progettati su misura per soddisfare le vostre esigenze specifiche. È possibile personalizzare i prodotti in base alle vostre esigenze specifiche.
Schema di installazione (normale)
Cerca
Tutti i prodotti
Contattaci
Cerchi la migliore soluzione di aria compressa per il tuo settore?
● Condividi le tue esigenze per una valutazione da parte di esperti (assistenza multilingue).
● Sviluppare soluzioni personalizzate, considerando opzioni quali livello IP, compressore e parti, lingua dello schermo, controllo remoto, aspetto, adattamento di tensione e temperatura, ecc.
● Avvio della produzione dopo la conferma dell'ordine (tempi di produzione standard: 20-25 giorni).
● Eseguire rigorosi test di qualità prima della spedizione.
● Assistenza tecnica a vita, ricambi originali e garanzia fino a 10 anni sul compressore.
Domande frequenti
What is a refrigerated compressed air dryer?
A refrigerated compressed air dryer is a device that removes moisture from compressed air by cooling it down to a temperature where the water vapor condenses and can be removed. This helps prevent corrosion and damage to pneumatic tools and equipment, and ensures that the compressed air is clean and dry for use in various industrial applications.
How does a refrigerated compressed air dryer work?
A refrigerated compressed air dryer works by cooling the compressed air to a temperature where water vapor condenses into liquid form and can be removed from the air stream. The compressed air enters the dryer and passes through a heat exchanger where it is cooled by refrigerant. The cooled air then enters a separator where the condensed water is removed and drained out of the system. The dry air is then reheated and exits the dryer.
How to repair a refrigerated compressed air dryer?
Repairing a refrigerated compressed air dryer can be a complex process and should only be attempted by a trained professional. However, some common troubleshooting steps include checking for power and refrigerant leaks, cleaning the condenser and evaporator coils, and replacing any faulty components such as the compressor or fan motor. It is important to follow Nanxiang guidelines and safety precautions when attempting any repairs.
